CFM12
Critical Flashing Module
The Power-Tronics CFM12 Critical Flashing
Module is a convenient and compact
optional build up module for all Power-
Tronics UVR and XR series Universal
Voltage Regulators. The CFM12 offers an
easy method to add a fully automatic battery
flashing unit to any generator.
The CFM12 is a unique Critical Flashing
Module designed specifically for generators
with very low AC residual voltage, brush-
type generators, and for any installation
where guaranteed buildup is required.
Operation is completely automatic and
installation into a Power-Tronics regulating
system is quick and easy.
Like the rest of our professional line of
products, the CFM12 is fully repairable!
None of the major electronic components
are encapsulated to facilitate prompt repair!
The entire unit is coated in a protective film
to insulate it from any contamination and
moisture that may be present.
Specifications
The CFM12 Critical Flashing Module is
compatible with all previous UVR and XR
series Universal Voltage Regulators as well
as select VR series voltage regulators. The
CFM12 is also a very simple upgrade for
installations using older Power-Tronics
BU120/240 or BU500 series buildup
modules!
Input Voltage:
120 / 208 or 240vac
Frequency:
50-400Hz
Buildup Pullout Voltage:
85-100vac
Output Voltage:
12vdc
Signal Input Voltage:
12 / 24 / 36vdc*
Maximum Continuous Output:
16adc
Minimum Field Resistance:
1Ω
Storage Device:
Rechargeable, Sealed Battery
Battery Charger Input Voltage:
120 / 240vac*
Physical Size:
6 x 6 x 3 in.
Weight:
3 lbs
Repairable:
Yes
* Voltage
MUST
be specified when placing order!
