DC250
DC Voltage Regulator
The Power-Tronics DC250 DC Voltage
Regulator is the latest upgrade for all Power-
Tronics DC and XR series DC voltage
regulators. The DC250 is also capable of
replacing other manufacturers' voltage
regulators or existing manually operated
controls!
The DC250 is a unique, DC Voltage Regulator
that is designed specifically for replacement of
vintage or obsolete DC generator voltage
regulation equipment such as manually operated
rheostats and/or resistor banks and offers
precise voltage regulation regardless of the
connected load and ambient temperature. The
DC250 is a ruggedized design and is engineered
to provide a lifetime of trouble-free operation.
PLC and automated control is possible with the
DC250 by simply adding an optional,
inexpensive digital interface module. This
capability makes the DC250 suitable for
automated or unattended installations.
Specifications
The DC250 DC Voltage Regulator has a unique
modular design to increase reliability and
facilitate repair should the need ever arise. The
DC250 is made up for separate control and firing
modules and contains a user-replaceable field
flashing relay. Because of its modular design,
the DC250 DC Voltage Regulator can be fitted
with rectifier modules of varying amperage
capacity from 10adc to 40adc to meet the needs
of a wide array of DC generators!
Input Voltage:
200-250vdc
Frequency:
DC
Voltage Regulation:
+/- 1% From NL to FL
Parallel Operation
No
Output Voltage:
0-250vdc @ 250vac input
Maximum Continuous Output:
10 / 20 / 40adc*
Minimum Field Resistance:
25Ω @ 10adc output*
10Ω @ 25adc output*
6.25Ω @ 40adc output*
Min Residual Build up Voltage:
5vdc
Physical Size:
10 x 10 x 4 in.
The DC250 is compatible with all previous and
current optional modules available for use with
Power-Tronics voltage regulators making it
extremely simple to upgrade an older voltage
regulator installation with the modern features
offered by the DC250.
Weight:
4 lb.
External Protection:
Customer-Supplied Fuses
External Voltage Adjustment:
Yes
Optional External Controls
Yes
*Amperage must be specified when ordering! Default amperage
configuration is 20adc!
