PC1500BF
Phase control
The Power-Tronics PC1500BF Phase
control is a self-contained complete Phase
control. The PC1500BF Phase control is
designed for continuous operation at up to
210vdc at 100adc!
The PC1500BF is uniquely designed to sit
in a compact footprint while being
passively convection cooled for a long
service life. Because of its unique
modular design, the PC1500BF minimizes
downtime should a repair ever be
necessary! The PC1500BF’s compact
design allows a wide variety of installation
methods, including installations where
space is at a premium.
The PC1500BF is a time-proven design,
utilizing high-reliability components and a
unique modular design to simplify repair.
The PC1500BF is designed to provide a
lifetime of service and is specifically built
to minimize failures and potential
downtime!
Specifications
The PC1500BF is also capable of
operation with Power-Tronics’ wide variety
of optional accessories, which allow the
PC1500BF to be remotely operated by dry
contact switching or by a PLC controller!
Input Voltage:
208 - 240vac
Frequency:
50 or 60 Hz
Control Range:
0-100%
Output Voltage:
0-210vdc @ 240vac input
Maximum Continuous Output:
100adc
Minimum Field Resistance:
2.1Ω @ 210vdc output
The PC1500BF Phase control is the latest
upgrade to the PC1500B series of phase
controls and replaces all previous Power-
Tronics PC1500B and PC1500BX Phase
controls!
Physical Size:
10 x 20 x 8 in.
Weight:
18 lb.
Phase control:
PC500X
Repairable:
Yes
Internal Protection:
Fuses, cartridge type
External Voltage Adjustment:
Yes
System Operating Indicator:
Yes
Optional External Controls
Yes
