PC500X
Universal Phase Control
The Power-Tronics PC500X Universal Phase
Control is the latest upgrade for all UVR and XR
series phase controls. The PC500X is also
capable of replacing other manufacturers' phase
controls and has optional Static Exciter Modules
to boost its capacity to 30 amps DC!
The PC500X is a unique, Universal Phase
Control that is designed specifically for
Professional Service Technicians and the
Electrical Repair Industry. It offers stable
voltage control regardless of the connected load
and ambient temperature. The PC500X is a
ruggedized design and is engineered to provide
a lifetime of trouble-free operation.
PLC and automated control is possible with the
PC500X by simply adding an optional,
inexpensive digital interface module. This
capability makes the PC500X suitable for
automated or unattended installations.
Specifications
Like our previous models, the PC500X is fully
repairable! All major electronic components are
not encapsulated to facilitate repair while all
sensitive components are encapsulated to
protect them from contamination and moisture.
Input Voltage:
120 / 208 or 240vac
Frequency:
50 or 60hz
Control Range:
0-100%
Output Voltage:
0-52vdc @ 120vac input
The PC500X is compatible with all previous and
current optional modules available for use with
Power-Tronics phase controls making it
extremely simple to upgrade an older phase
control installation with the modern features
offered by the PC500X.
0-105vdc @ 240vac input
0-210vdc @ 240vac input
Maximum Continuous Output:
5adc
Minimum Field Resistance:
10.5Ω @ 52vdc output
21Ω @ 105vdc output
42Ω @ 210vdc output
Physical Size:
4.75 x 6 x 1 in.
Weight:
7 oz
Repairable:
Yes
Internal Protection:
Fuses, cartridge type
External Voltage Adjustment:
Yes
System Operating Indicator:
Yes
Optional Static Exciter Modules
Yes
Optional External Controls
Yes
