SE2000AF
Static Exciter
The Power-Tronics SE2000AF Static
Exciter is a self-contained complete Static
Exciter. The SE2000AF Static Exciter is
designed for continuous operation at up to
105vdc at 200adc!
The SE2000AF is uniquely designed to sit
in a compact footprint while being
passively convection cooled for a long
service life. Because of its unique
modular design, the SE2000AF minimizes
downtime should a repair ever be
necessary! The SE2000AF’s compact
design allows a wide variety of installation
methods, including installations where
space is at a premium.
The SE2000AF is a time-proven design,
utilizing high-reliability components and a
unique modular design to simplify repair.
The SE2000AF is designed to provide a
lifetime of service and is specifically built
to minimize failures and potential
downtime!
Specifications
The SE2000AF is also capable of parallel
operation with other generators or with a
utility buss. Power-Tronics’ wide variety of
optional accessories also allows the
SE2000AF to be remotely operated by dry
contact switching or by a PLC controller!
Input Voltage:
208 - 240vac
Frequency:
50 or 60 Hz
Voltage Regulation:
+/- .25% From NL to FL
Parallel Operation
Yes
Output Voltage:
0-105vdc @ 240vac input
Maximum Continuous Output:
200adc
Minimum Field Resistance:
.52Ω @ 105vdc output
The SE2000AF Static Exciter is the latest
upgrade to the SE2000A series of static
exciters and replaces all previous Power-
Tronics SE2000A and SE2000AX Static
Exciters!
Min Residual Build up Voltage:
3.5vac
Under Frequency Protection:
Yes, VPH reduction
Physical Size:
24 x 12 x 10 in.
Weight:
23 lb.
Voltage Regulator:
XR500D
Internal Build-Up Provisions:
Yes, AFM500X Auto-Flash
Repairable:
Yes
Internal Protection:
Fuses, cartridge type
External Voltage Adjustment:
Yes
System Operating Indicator:
Yes
Optional External Controls
Yes
