SE500B
Static Exciter
The Power-Tronics SE500B Static Exciter
is a self-contained complete Static Exciter.
The SE500B Static Exciter is designed for
continuous operation at up to 210vdc at
50adc!
The SE500B is uniquely designed to sit in
a compact footprint while being passively
convection cooled for a long service life.
Because of its unique modular design, the
SE500B minimizes downtime should a
repair ever be necessary! The SE500B’s
compact design allows a wide variety of
installation methods, including installations
where space is at a premium.
The SE500B is a time-proven design,
utilizing high-reliability components and a
unique modular design to simplify repair,
using standard stocked components. The
SE500B is designed to provide a lifetime
of service and is specifically built to
minimize failures and potential downtime!
Specifications
The SE500B is also capable of parallel
operation with other generators or with a
utility buss. Power-Tronics’ wide variety of
optional accessories also allows the
SE500B to be remotely operated by dry
contact switching or by a PLC controller!
Input Voltage:
208 - 240vac
Frequency:
50 or 60 Hz
Voltage Regulation:
+/- .25% From NL to FL
Parallel Operation
Yes
Output Voltage:
0-210vdc @ 240vac input
Maximum Continuous Output:
50adc
Minimum Field Resistance:
4.2Ω @ 210vdc output
The SE500B Static Exciter is designed to
incorporate a fully featured dual SE450 +
XR500D installation on a single mounting
plate to provide a professional
appearance, factory installed wiring to
minimize guesswork, and a finished
product to minimize installation time!
Min Residual Build up Voltage:
3.5vac
Under Frequency Protection:
Yes, VPH reduction
Physical Size:
12 x 10 x 4 in.
Weight:
6 lb.
Voltage Regulator:
XR500D
Static Exciter Module:
SE450 (2 MODULES)
Internal Build-Up Provisions:
Yes, AFM500X Auto-Flash
Repairable:
Yes
Internal Protection:
Fuses, cartridge type
External Voltage Adjustment:
Yes
System Operating Indicator:
Yes
Optional External Controls
Yes
