XR500D-180
Universal Voltage Regulator
The Power-Tronics XR500D-180 Universal
Voltage Regulator is the latest upgrade for all
UVR and XR series voltage regulators. The
XR500D-180 is also capable of replacing other
manufacturers' voltage regulators and has
optional Static Exciter Modules to boost its
capacity to 30 amps DC!
The XR500D-180 is a unique, Universal voltage
regulator that is designed specifically for
Professional Electrical Generator Service
Technicians and the Electrical Generator Repair
Industry. It offers precise voltage regulation
regardless of the connected load and ambient
temperature. The XR500D-180 is a ruggedized
design and is engineered to provide a lifetime of
trouble-free operation.
The XR500D-180 contains patented electronic
circuitry that automatically matches the
regulator's response time to the generator
exciter. This unique innovation eliminates the
need to manually adjust stability when setting up
the voltage regulator and greatly simplifies
installation.
Specifications
PLC and automated Genset control is possible
with the XR500D-180 by simply adding an
optional, inexpensive digital interface module.
This capability makes the XR500D-180 suitable
for automated or unattended installations, or
large-scale parallel operations.
Input Voltage:
120 / 208 or 240vac
Frequency:
180hz
Voltage Regulation:
+/- .25% From NL to FL
Parallel Operation
Yes
Output Voltage:
0-52vdc @ 120vac input
Like our previous models, the XR500D-180 is
fully repairable! All major electronic components
are not encapsulated to facilitate repair while all
sensitive components are encapsulated to
protect them from contamination and moisture.
0-105vdc @ 240vac input
0-210vdc @ 240vac input
Maximum Continuous Output:
5adc
Minimum Field Resistance:
10.5Ω @ 52vdc output
21Ω @ 105vdc output
42Ω @ 210vdc output
Min Residual Build up Voltage:
3.5vac
Under Frequency Protection:
No
The XR500D-180 is compatible with all previous
and current optional modules available for use
with Power-Tronics voltage regulators making it
extremely simple to upgrade an older voltage
regulator installation with the modern features
offered by the XR500D-180.
Physical Size:
4.75 x 6 x 1 in.
Weight:
7 oz
Repairable:
Yes
Internal Protection:
Fuses, cartridge type
External Voltage Adjustment:
Yes
System Operating Indicator:
Yes
Optional Static Exciter Modules
Yes
Optional External Controls
Yes
